Attaches one 26V battery to the back of ARRI Alexa LF, 65, and SXT cameras.
Prioritized 2pin DC input to support block batteries with hot-swap backup and OLED screen for voltage information. Includes two regulated 15V P-Tap ports enabling Dionic 26V batteries to be swapped without the need to disconnect P-TAP powered accessory cables.
Can be used in conjunction with Anton/Bauer VCLX battery to allow hot swap capability without the need for powering down the camera.
Also known as Wooden Camera - 26V Gold Mount (Alexa LF, 65, SXT) - SKU 273000
Compatibility
Anton Bauer Plate 26V Gold Mount Plus attach 1x26V battery to ARRI Alexa LF & 65 & SXT cameras
Key Features
- Wooden Camera / Anton Bauer 26V Gold Mount Plus Plate enables a single Dionic 26V battery to power an Alexa LF, 65, or SXT Camera
- Plate attaches to the back of the ARRI Alexa LF, 65, or SXT cameras through battery contacts without cables
- Internal circuit board prioritizes the 2pin Fischer DC Input, allowing 24V block batteries to be used first, leaving the on-board battery fully charged
- Hot swapping between battery sources is possible and OLED screen provides voltage data, battery capacity, and active source information
- Two P-TAPS provide regulated 15V power
- Plate includes a ""digital reset"" through the OLED if current thresholds are exceeded and cuts power to the P-TAPs
